Huawei RRU5909 02311PPP
Huawei RRU5909 02311PPP WD5M18590900 B3 1800M 2T2R
The Huawei RRU5909 (Part Number: 02311PPP) is a remote radio unit used in wireless base station systems such as the Huawei DBS3900 and DBS5900.
Technical Specifications:
• Product Name: Huawei RRU5909
• Part Number / Material Code: 02311PPP (also referenced as WD5M18590900 or WD5MERULC30B)
• Frequency Band: Band 3 (1800 MHz)
• TX Frequency Range: 1805 MHz – 1880 MHz
• RX Frequency Range: 1710 MHz – 1785 MHz
• Configuration / Architecture: 2T2R (2 Transmit 2 Receive)
• Output Power: 2 × 60W (Total 120W)
• Power Supply: -48V DC
• Compatibility / System: DBS3900 / DBS5900 multi-mode base station series
