Huawei RRU5258 02312AFL
Huawei outdoor Remote Radio Unit RRU5258 (Part Number: 02312AFL, Model Code: WD5MPRUGHA00)
The Huawei RRU5258 (Part Number: 02312AFL, Model Code: WD5MPRUGHA00) is an outdoor Remote Radio Unit (RRU) designed for multi-mode wireless base stations.
Key Specifications & Features:
• Part Number (PN): 02312AFL
• Module Code: WD5MPRUGHA00
• Supported Frequency Band: 3400 MHz – 3600 MHz (Multi-Mode / 3500 MHz Band 42)
• Supported Standards: LTE TDD and NR TDD (5G)
• Instantaneous Bandwidth (IBW): 200 MHz
• Occupied Bandwidth (OBW): LTE TDD up to 120 MHz, NR TDD up to 200 MHz
• Core Functions: Remote RF processing, transmit/receive (TX/RX) signal conversion, filtering, and multiplexing
