Huawei 02314PHV SFP-10GBaseT-SR
Huawei Original 02314PHV SFP-10GBaseT-SR
| Item | Value |
|---|---|
| Basic Information | |
| Module name | SFP-10GBaseT-SR |
| Part Number | 02314PHV |
| Model | SFP-10GBaseT-SR |
| Form factor | SFP+ |
| Application standard | 10GBASE-T |
| Connector type | RJ45 |
| Optical fiber type | – |
| Working case temperature [°C(°F)] | –5°C to +85°C (23°F to 185°F)
When a switch uses this module, the ambient temperature must range from –5°C to +50°C (23°F to 122°F) |
| Digital diagnostic monitoring (DDM) | Not supported |
| Transmission rate [bit/s] | 100 Mbit/s
1 Gbit/s 2.5 Gbit/s 5 Gbit/s 10 Gbit/s |
| Target transmission distance [km] | 10 Gbit/s: 30 m (Cat6A S/FTP or above)
2.5 Gbit/s or 5 Gbit/s: 30 m (Cat5E STP or above) 100 Mbit/s or 1 Gbit/s: 100 m (Cat5E or above) |
| Transmitter Optical Characteristics | |
| Center wavelength [nm] | – |
| Maximum Tx optical power [dBm] | – |
| Minimum Tx optical power [dBm] | – |
| Minimum extinction ratio [dB] | – |
| Receiver Optical Characteristics | |
| Rx sensitivity [dBm] | – |
| Overload power [dBm] | – |
|
NOTE:
When a switch uses this module, the ambient temperature must range from 0°C to 45°C (32°F to 113°F).
|
|
