XGPON OLT N2a Module
Huawei XGPON OLT N2a optical transceiver applied to XGPON board XGBD, XGBC, XGHD, XGSF.
Huawei XGPON OLT N2a module applied to XGPON board XGBD, XGBC, XGHD, XGSF.
| Specification | ||
| Type | N2a | |
| Operating Wavelength | Tx: 1577nm Rx:1270nm | |
| Encapsulation Type | SFP+ | |
| Port Rate | Tx: 9.953Gbit/s Rx: 2.488Gbit/s |
|
| Minimum Output Optical Power | 4dBm | |
| Maximum Output Optical Power | 8dBm | |
| Maximum Receiver Sensitivity | -29.5dBm | |
| Optical Connector Type | SC | |
| Optical Fiber Type | Single-mode | |
| Overload Optical Power | -9dBm | |
| Extinction Ratio | 8.2dB | |
