NE8000 M4 Router
Huawei Ne8000 M4 Router DC
NE 8000 – M4
The NetEngine 8000-M4 is a multi-service router measuring only 2U in height and 220mm in depth, serving up to 64k PPPoE/IPoE users and up to 1.2Tb of forwarding.Its four service slots provide 100GE, 50GE, 40GE, 25GE, 10GE and GE ports that flexibly adapt to different scenarios.It supports major protocols such as BGP, OSPF, MPLS, SRv6 and EVPN, and its compact design saves space and significantly reduces CAPEX.
| Maximum Switching Capacity | 2.4 Tbit/s |
| Maximum Forwarding Capacity | 455 Mpps |
| Maximum plate capacity | 200 Gbit/s |
| Capacity density(G/U) | 800 |
| Controller board | Integrada |
| SFU | 2, 1+1 (integrada) |
| CPU | 16-core, 2.0 GHz |
| SDRAM | 16GB |
| Storage | 16 GB |
| Flash memory | 64MB |
| Number of Service Plates | 4 |
| Maximum number of ports 10GE | 72 |
| Maximum number of ports FE | 96 |
| Maximum number of ports 50GE | 12 |
| Maximum number of ports 25GE | 64 |
| Maximum number of ports GE | 96 |
| Maximum number of electrical ports | 96 |
| Maximum number of ports 100GE | 12 |
| Maximum number of ports 40GE | 12 |
| Power supplies | There are two, one of redundancy |
| Ventilation module | There are two, one of redundancy |
| Dimensions (A x L x P) | 88,9 x 442 x 220 mm (2U) |
| Weight (full) | 7,2 Kg |
| Maximum current | 30 A |
| Typical energy consumption | 1200 W |
| Input Voltage | -40 V to -72 V |
| Operating Temperature | -20°C to +60°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| MTBF | 33,40 years |
| MTTR | 0.5 hours |
| Parameter | NetEngine 8000 X8 | NetEngine 8000 X4 | NetEngine 8000 M14 | NetEngine 8000 M8 | NetEngine 8000 M6 | NetEngine 8000 M1A | NetEngine 8000 F1A |
| Switching Capacity |
83.78 Tbit/s | 41.89 Tbit/s | 4 Tbit/s | 2.4 Tbit/s | 320 Gbit/s | 352 Gbit/s | 2.4 Tbit/s |
| Forwarding Performance |
14,496 Mpps | 7248 Mpps |
906 Mpps | 453 Mpps | 72 Mpps | 72 Mpps | 453 Mpps |
| Max. Capacity of a Board | 4 Tbit/s | 4 Tbit/s | 200 Gbit/s | 200 Gbit/s | 50 Gbit/s | Fixed-configuration router does not support flexible cards | Fixed-configuration router does not support flexible cards |
| Capacity Density (G/U) | 2025 | 1633 | 400 | 400 | 80 | 176 | 1200 |
| IPU | 2, 1:1 | 2, 1:1 | 2, 1:1 | 2, 1:1 | 2, 1:1 | Fixed-configuration router does not support flexible cards | Fixed-configuration router does not support flexible cards |
| SFU | 8, 7+1 | 8, 7+1 | 2, 1:1 (integrated) |
2, 1:1 (integrated) |
2, 1:1 (integrated) |
Fixed-configuration router does not support flexible cards | Fixed-configuration router does not support flexible cards |
| Processing Board/ Subcard |
8 | 4 | 14(DC) 10(AC) |
8(DC) 6(AC) |
6(DC) 4(AC) |
Fixed-configuration router does not support flexible cards | Fixed-configuration router does not support flexible cards |
| Power Supply Module | Max 10, N+1 | Max 6, N+1 | 2, 1+1 (DC) 4, 2+2 (AC) |
2, 1+1 | 2, 1+1 | 2, 1+1 (DC) | 2, 1+1 |
| Fan Module |
12, 11+1 | 6, 5+1 | 4, 3+1 | 2, 1+1 | 2, 1+1 | 3 (integrated) | 4, 3+1 |
| Dimensions (H x W x D) |
702.3 x 442 x 861.4 mm (15.8 U) | 435.6 x 442 x 861.4 mm (9.8 U) | 222 x 442 x 220 mm (5 U) | 132.6 x 442 x 220 mm (3 U) | 88.9 x 442 x 220 mm (2 U) | 44.45 x 442 x 220 mm (1 U) | 43.6 x 442 x 420 mm (1 U) |
| Typical Power Consumption | 11,017 W | 5913 W | 1270 W | 485 W | 220 W | 75 W | 350 W |
| Weight (With Full Configuration) |
296.6 kg | 186.2 kg | 27.4 kg | 16.5 kg | 3.52 kg | 3.4 kg | 7.25 kg |
