Huawei S5700-28X-PWR-LI-AC
Huawei S5700-28X-PWR-LI-AC switch with 24-ports 1000BASE-T, 4-ports 10GE SFP+, 1xAC power fixed.
Huawei Quidway S5700 series gigabit enterprise switches is designed for high-bandwidth access and Ethernet aggregation. Huawei Quidway S5700 can be used in various campus network scenarios: access switch, aggregation switch, gigabit access switch in Internet data center, or desktop switch to provide 1000 Mbps access for terminals.
Tech Specs:
| Item | Description |
| Memory (RAM) | 256 MB |
| Flash | 200 MB |
| Mean time between failures (MTBF) | 61.53 years |
| Mean time to repair (MTTR) | 2 hours |
| Availability | > 0.99999 |
| Service port surge protection | Common mode: ±6 kV |
| Power supply surge protection | ±6 kV in differential mode, ±6 kV in common mode |
| Dimensions (H x W x D) | 43.6 mm x 442.0 mm x 310.0 mm (1.72 in. x 17.4 in. x 12.2 in.) |
| Weight (with packaging) | 4.7 kg (10.36 lb) |
| Stack ports | Four uplink 10GE SFP+ ports |
| RTC | Supported |
| RPS | Supported |
| PoE | Supported |
| Rated voltage range | 100 V AC to 240 V AC, 50/60 Hz |
| Maximum voltage range | 90 V AC to 264 V AC, 47 Hz to 63 Hz |
| Maximum power consumption (100% throughput, 100% PoE loads, full speed of fans) | 448.8 W (system power consumption: 78.8 W, PoE: 370 W) |
| Typical power consumption (30% of traffic load) | 39.4 W |
| Tested according to ATIS standard | |
| EEE enabled | |
| No PoE power consumption | |
| Operating temperature | 0°C to 50°C (32°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) |
| NOTE: | |
| When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). | |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) |
| Noise under normal temperature (27°C, sound power) | < 49.5 dB(A) |
| Relative humidity | 5% to 95%, noncondensing |
| Operating altitude | 0-5000 m (0-16404 ft.) |
| Certification | EMC certification |
| Safety certification | |
| Manufacturing certification | |
| Part number | 02354217 |
