Huawei Original EchoLife HN8255Ws
HN8255Ws is XGS-PON routing-type ONT with 4xGE+1x10GE+2xPOTS+1 USB+2.4G&5G WiFi.
Huawei EchoLife HN8255Ws is an XGS-PON routing-type ONT in the all-optical access solution. The product adopts the XGS-PON technology to implement ultra-broadband access for users. At the same time, it offers 4 GE+1 10GE+2 POTS+2 USB+2 WiFi (4 GE ports, 1 10GE port,2 POTS ports, 2 USB port, 1 2.4G WiFi port and 1 5G WiFi port). The high forwarding performance ensures the user experience of voice, data and HD video services, and gives customers with an ideal all-optical access solution and future-oriented service support capability.
| Model | HN8255Ws |
| Dimensions (H x W x D) | 198 mm x 305 mm x 82.5 mm |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 5% RH to 95% RH (non-condensing) |
| Power adapter input | 100-240 V AC, 50/60 Hz |
| System power supply | 11-14 V DC, 4 A |
| Maximum power consumption | 46.5 W |
| Port | 2 x POTS + 4 x GE + 1 x 10GE +2.4G&5G Wi-Fi + 2 x USB |
| Static power consumption | 9.6 W |
| Indicators | Power/PON/LOS/TEL/10G LAN/ |
| LAN/WLAN/WPS/USB | |
| NNI | XGS-PON ( SFP+ Optical Module ) |
