Huawei 10G-1310nm-10km-SM-SFP+

Huawei Original 10G-1310nm-10km-SM-SFP+ Optical Transceiver Module 34060742

Basic Information
Part Number	34060742
Model	OSX010N30
Description	Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2~0.5dBm,-12.6dBm,LC,SM,10km)
Level-1 category	10Gbps SFP+ Optical Module
Module name	10Gbps-SFP+-SMF-1310nm-10km-commercial
Technical Specifications
Connector type	LC
Optical fiber type	SMF
Form factor	SFP+
Transmission rate [bit/s ]	9.953 Gbit/s 10.3125 Gbit/s
Target transmission distance [km]	10 km
Application standard	IEEE 802.3ae, 10GBASE-LR/LW
Working case temperature [°C(°F)]	0°C to 70°C(32°F to 158°F)
Center wavelength [nm]	1310 nm
Overload power (OMA) [dbm]	-
Overload power (AVG) [dbm]	0.5 dBm
Minimum Tx optical power (OMA) [dbm]	-
Minimum Tx optical power (AVG) [dbm]	-8.2 dBm
Maximum Tx optical power (OMA) [dbm]	-
Maximum Tx optical power (AVG) [dbm]	0.5 dBm
Minimum extinction ratio [db]	3.5 dB
Rx operating wavelength range [nm]	1260 nm - 1355 nm
Tx operating wavelength range [nm]	1260 nm - 1355 nm
Rx sensitivity (OMA) [dbm]	-12.6 dBm
Rx sensitivity (AVG) [dbm]	-14.4 dBm
DDM options	SFF-8472
Bit error ratio (BER)	<1x10E-12
Environment standard	RoHS
Security standard	FCC Class B, IEC 60825-1 Class 1
ESD(HBM1)	500
