H901OGHK interface board
Huawei H901OGHK is 48-channels GE/FE P2P interface board.
Huawei OGHK Board is 48-port aggregated GE/FE optical interface board, supporting up to 48 channels of GE/FE
Huawei OGHK Board Features:
H901OGHK is a 48-port GE/FE optical interface board that provides Ethernet optical access function. It supports up to 48 GE/FE P2P access, suitable for Ethernet access.
Support 48 channels (CSFP) or 24 channels (SFP) GE/FE P2P optical access
Support cascading and convergence
Support dual channel single fiber bidirectional CSFP optical module, single channel dual fiber bidirectional optical module (SFP) and single channel single fiber bidirectional optical module (SFP)
GE port supports synchronous Ethernet clock delivery function
Support temperature query and high temperature alarm
Support high temperature automatic shutdown protection
Support continuous business of software upgrades
Support for reading the status of the optical module (status, optical power, temperature, etc.)
Huawei OGHK Service Board Product Specifications:
| Part Number | 03022SQT |
| Model | OGHK |
| Product Description | 48-port Advanced GE/FE Optical Interface Board |
| Product Series | MA5800-X7 MA5800 X15 MA5800X17 MA5800-X2 |
| Dimensions (H x W x D) | 442 mm x 268.7 mm x 263.9 mm |
| Maximum Number of Ports in a Subrack | 112 x GPON/EPON |
| 336 x GE/FE | |
| 56 x 10G GPON/10G EPON | |
| 56 x 10G GE | |
| 224 x E1 | |
| Switching Capacity of the System | 7 Tbit/s |
| Maximum Number of MAC Addresses | 262,143 |
| Maximum Number of ARP/Routing Entries | 64K |
| Ambient Temperature | -40°C to 65°C |
| Note: The MA5800 can start up at a lowest temperature of -25°C and run at -40°C. The 65°C temperature refers to the highest temperature measured at the air intake vent | |
| Working Voltage Range | -38.4V DC to -72V DC |
| Layer 2 Features | VLAN + MAC forwarding, SVLAN + CVLAN forwarding, PPPoE+, and DHCP option82 |
| Layer 3 Features | Static route, RIP/RIPng, OSPF/OSPFv3, IS-IS, BGP/BGP4+, ARP, DHCP relay, and VRF |
| MPLS & PWE3 | MPLS LDP, MPLS RSVP-TE, MPLS OAM, MPLS BGP IP VPN, tunnel protection switching, TDM/ETH PWE3, and PW protection switching |
| IPv6 | IPv4/IPv6 dual stack, IPv6 L2 and L3 forwarding, and DHCPv6 relay |
| Multicast | IGMP v2/v3, IGMP proxy/snooping, MLD v1/v2, MLD Proxy/Snooping, and VLAN-based IPTV multicast |
| QoS | Traffic classification, priority processing, trTCM-based traffic policing, WRED, traffic shaping, HqoS, PQ/WRR/PQ + WRR, and ACL |
| System Reliability | GPON type B/type C protection, 10G GPON type B protection, BFD, ERPS (G.8032), MSTP, intra-board and inter-board LAG, In-Service Software Upgrade (ISSU) of the control board, 2 control boards and 2 power boards for redundancy protection, in-service board fault detection and rectification, and service overload control |
